VW Golf 4

Manufacturers

VW Golf 4

VW Golf 4

VW Golf 4

There are 42 products.

Subcategories

  • VW Golf 4 1.8T 150hp AGU AQA ARZ AUM AWD 1997-2005
    VW Golf 4 1.8T 150hp AGU AQA ARZ AUM AWD 1997-2005

    The 150hp VW Golf 4 1.8T 20V, built from 1997 to 2005, uses the EA113 with codes AGU, AQA, ARZ, AUM or AWD. Eighteen active references.

    What sets this page apart from the 180hp GTI: ZRP H-Lite long forged con rods with 147.2mm centre to centre length, 20mm pin, ARP2000 or L19 bolts.

    1.8T forged pistons by DIAMOND, JE, SUPERTECH, WISECO or WOSSNER from 81mm; 12 intake and 12 exhaust valves by SUPERTECH or FERREA, springs, CATCAMS cam followers, SUPERTECH guides, stem seals and collets; ARP2000 and 8740 studs, COMETIC or ATHENA gasket, ACL RACE or KING RACING bearings, uprated clutch.

  • VW Golf 4 GTI 1.8T 180hp AUQ BEK 2001-2005
    VW Golf 4 GTI 1.8T 180hp AUQ BEK 2001-2005

    The 180hp VW Golf 4 GTI 1.8T 20V, built from 2001 to 2005, uses the EA113 with codes AUQ or BEK. Nineteen active references.

    What sets it apart from the 150hp: a set of 4 ZRP I-beam forged con rods for a 19mm pin, whose sheet names the AUQ, and the CATCAMS vernier cam pulley for the 06A block, in 7075 aluminium, ±10° adjustment in 1° steps.

    Shared base: 1.8T forged pistons by DIAMOND, JE, SUPERTECH, WISECO or WOSSNER, SUPERTECH or FERREA valves, springs, CATCAMS cam followers, SUPERTECH guides and seals, ARP studs, COMETIC or ATHENA gasket, ACL RACE or KING RACING bearings, uprated clutch.

  • VW Golf 4 VR5 2.3 10V 150hp AGZ 1997-2006
    VW Golf 4 VR5 2.3 10V 150hp AGZ 1997-2006

    The 150hp VW Golf 4 VR5 2.3 10V, built from 1997 to 2006, uses the AGZ, a five-cylinder V engine with 10 valves. This page carries a single active reference.

    It is the VR5 AGZ forged piston set, rings included, 20mm gudgeon pin, in two ranges: WISECO in 82, 82.5 or 83mm bore at 9:1, or JE Round at 83mm and 8:1, a low ratio intended for forced induction.

    No con rod, bearing or head part is linked to this engine so far.

  • VW Golf 4 VR5 2.3 20V 170hp AQN 2000-2006
    VW Golf 4 VR5 2.3 20V 170hp AQN 2000-2006

    The 170hp VW Golf 4 VR5 2.3 20V, built from 2000 to 2006, uses the AQN, the 20-valve version of the V five-cylinder. This page carries a single active reference.

    It is the VR5 20V forged piston set, 20mm gudgeon pin, in two ranges: WOSSNER at the stock 10.8:1 ratio in 81, 82, 82.5 or 83mm bore, for a naturally aspirated build, or WISECO at 8:1 in 81 to 82mm, for a turbo build.

    No con rod, bearing or head part is linked to this engine so far.

  • VW Golf 4 VR6 2.8 204hp AQP AUE 1999-2006
    VW Golf 4 VR6 2.8 204hp AQP AUE 1999-2006

    The 204hp VW Golf 4 VR6 2.8 24V, built from 1999 to 2006, uses the AQP or AUE. Fifteen active references, the same as on the BDE page apart from the camshaft.

    Head: CATCAMS sport camshafts specific to the AQP and AUE, from 7607601 to 7607605; CATCAMS springs or FERREA S10087 spring and FERREA E11063 titanium retainer, single or as a kit; ATHENA MLS gasket.

    Bottom end: VR6 24V forged pistons by JE Round, WOSSNER or WISECO from 81 to 83mm, 20mm pin; 6 BOOSTLINE or ZRP con rods; ACL RACE or KING RACING bearings; ARP fasteners. FIC injectors, VIBRA-TECHNICS mounts.

  • VW Golf 4 VR6 2.8 204hp BDE 1999-2006
    VW Golf 4 VR6 2.8 204hp BDE 1999-2006

    The 204hp VW Golf 4 VR6 2.8 24V uses the BDE here. Fifteen active references, identical to those of the AQP AUE page except for the camshaft.

    Valve train: CATCAMS sport camshafts for the BDE, shared with the R32 BFH and BML, from 7607421 to 7607502. CATCAMS springs, FERREA S10087 spring and FERREA E11063 titanium retainer.

    Bottom end: VR6 24V forged pistons by JE Round, WOSSNER or WISECO in 81 to 83mm, ratio from 8.5 to 10.8:1; set of 6 BOOSTLINE I-3P or ZRP I-HD con rods; ACL RACE or KING RACING big end, main bearings and thrust washers; ARP 8740 main studs, ARP2000 con rod bolts.

    ATHENA MLS gasket, FIC injectors, VIBRA-TECHNICS mounts.

  • VW Golf 4 R32 241hp BFH BML 2002-2005
    VW Golf 4 R32 241hp BFH BML 2002-2005

    The 241hp VW Golf 4 R32, built from 2002 to 2005, uses the 3.2 VR6 24V BFH or BML. Nineteen active references.

    Head: CATCAMS sport camshafts from 7607421 to 7607502, 24 cam followers and shims, CATCAMS vernier sprocket; 12 intake and 12 exhaust valves by SUPERTECH or FERREA, OEM or +1.00mm; CATCAMS or SUPERTECH springs, 48 SUPERTECH 6mm collets; COMETIC MLS gasket at 85.0mm in 17 thicknesses.

    Bottom end: R32 forged pistons by DIAMOND, JE Round, WISECO or WOSSNER from 84mm, 20mm pin; 6 BOOSTLINE or ZRP con rods; ACL RACE, KING RACING or KING RACE bearings; ARP fasteners. FIC injectors, VIBRA-TECHNICS mounts.

Showing 1 - 42 of 42 items
VW Golf 4
The Golf 4 is the most branched generation in terms of engines: seven sub-pages, from the 150bhp 1.8T coded AGU, AQA, ARZ, AUM and AWD up to the 241bhp R32 coded BFH and BML, by way of the 180bhp GTI 1.8T, the 10- and 20-valve VR5 2.3 units and the 204bhp VR6 2.8. Forty-one live lines are attached directly. The R32 forged pistons are chosen between four brands at 84mm, from 8:1 at Wiseco to 11.5:1 at JE Pistons. Two head gaskets coexist, Athena for the 12- and 24-valve VR6 and Cometic for the R32. Kent Cams belt, Supertech springs, King Race and ACL bearings, ARP fasteners.
