VW New Beetle 9C

Manufacturers

VW New Beetle 9C

VW New Beetle 9C

VW New Beetle 9C

There are 40 products.

Subcategories

  • VW New Beetle 1.8T 150hp AGU APH AVC AWU AWV BKF 1999-2010
    VW New Beetle 1.8T 150hp AGU APH AVC AWU AWV BKF 1999-2010

    The 150hp VW New Beetle 1.8T 20V, built from 1999 to 2010, uses the EA113 with codes AGU, APH, AVC, AWU, AWV or BKF. Seventeen active references.

    What sets this page apart from the 180hp AWP BNU: ZRP H-Lite long forged con rods with 147.2mm centre to centre length, 20mm pin, ARP2000 or L19 bolts, whose sheet names the AGU, AVC and AWU.

    1.8T forged pistons by DIAMOND, JE, SUPERTECH, WISECO or WOSSNER from 81mm; 12 intake and 12 exhaust valves by SUPERTECH or FERREA, springs, CATCAMS cam followers, SUPERTECH guides, stem seals and collets; ARP2000 and 8740 studs, COMETIC or ATHENA gasket, ACL RACE or KING RACING bearings, VIBRA-TECHNICS New Beetle mounts.

  • VW New Beetle 1.8T 180hp AWP BNU 2001-2005
    VW New Beetle 1.8T 180hp AWP BNU 2001-2005

    The 180hp VW New Beetle 1.8T 20V, built from 2001 to 2005, uses the EA113 with codes AWP or BNU. Sixteen active references, all also listed on the 150hp page.

    1.8T forged pistons by DIAMOND, JE, SUPERTECH, WISECO or WOSSNER from 81mm; 12 intake and 12 exhaust valves by SUPERTECH or FERREA, springs, CATCAMS cam followers, SUPERTECH guides, stem seals and collets; ARP2000 and 8740 studs, COMETIC or ATHENA gasket, ACL RACE or KING RACING bearings, VIBRA-TECHNICS New Beetle mounts.

    No forged con rod is linked to this page so far: the ZRP long rods of the 150hp name neither the AWP nor the BNU.

  • VW New Beetle VR5 2.3 20V 170hp AQN 2000-2010
    VW New Beetle VR5 2.3 20V 170hp AQN 2000-2010

    The 170hp VW New Beetle VR5 2.3 20V, built from 2000 to 2010, uses the AQN, the 20-valve version of the V five-cylinder. This page carries a single active reference.

    It is the VR5 20V forged piston set, 20mm gudgeon pin, in two ranges: WOSSNER at the stock 10.8:1 ratio in 81, 82, 82.5 or 83mm bore, for a naturally aspirated build, or WISECO at 8:1 in 81 to 82mm, for a turbo build.

    No con rod, bearing or head part is linked to this engine so far.

Showing 1 - 40 of 40 items
VW New Beetle 9C
The New Beetle 9C comes in three engine versions, the 150bhp 1.8T coded AGU, APH, AVC, AWU, AWV and BKF, the 180bhp 1.8T coded AWP and BNU, and the 170bhp VR5 2.3 20V coded AQN. Forty live lines are attached directly to it, sitting at the crossing of those blocks and the generic EA111, EA211 and EA888 families shared with the rest of the group. The brands established across this set are Kent Cams for the timing belt, Supertech and Ferrea for the collets and valve stem seals. An uprated engine and gearbox mount specific to the model's 1.8T 20V is available too.
