HONDA Civic X since 2016
Manufacturers
HONDA Civic X since 2016
Subcategories
This page brings together the cylinder head parts listed for the HONDA 1.8 16V R18Z1 of the Civic X FC6. All four references are SUPERTECH and share the same 5.5mm stem diameter. The valve stem seals are sold in sets of 8, separately for the intake (VS-H5.5I-8) and for the exhaust (VS-H5.5E-8), so only the side being worked on needs replacing. Valve collets complete the range, in kits of 16 or 32 depending on how many valves are removed. No pistons, connecting rods or head gasket are listed on this page.
The parts gathered here cover the HONDA 1.8 16V R18Z1 of the Civic X iVTEC FK5. SUPERTECH is the only brand listed, across four references with a 5.5mm stem diameter. The valve collets come in two pack sizes: a kit of 16 pieces for eight valves and a kit of 32 pieces for sixteen valves, that is a full cylinder head. Valve stem seals are available alongside them, in sets of 8, in an intake version and an exhaust version. This page carries no bottom end parts and no uprated studs or bolts.
This page brings together the engine parts listed for the HONDA 1.5 turbo L15B7 of the Civic X Coupe 170HP. The bottom end is its core: forged pistons are offered in two bores, 73mm and 73.5mm, and in five compression ratios from 9:1 to 12.5:1, from JE PISTONS, WÖSSNER and WISECO. The low ratio suits a build running high boost pressure, the high ratio a lightly tuned engine. ACL RACE and KING RACING thrust washers complete the bottom end, while cylinder head parts and uprated studs and bolts are also listed here.
The HONDA 1.5 turbo L15B7 of the Civic X Coupe 177HP is served here by a full cylinder head range from SUPERTECH. The performance valves are sold in sets of 8, separately for the intake and the exhaust, with a 5.5mm stem diameter matched by the valve stem seals and the valve collets, the latter in kits of 16 or 32. Uprated valve springs come in sets of 16. Forged pistons in 73mm and 73.5mm, ARP studs and bolts, and crankshaft thrust washers are also listed on this page.
For the HONDA 1.5 turbo L15B7 of the Civic X Coupe Si FC1 205HP, uprated ARP fasteners take first place: head studs and con rod bolts, the two parts that govern how a boosted engine holds together before any increase in boost pressure. Crankshaft thrust washers are available from ACL RACE and KING RACING. The page also carries forged pistons from JE PISTONS, WÖSSNER and WISECO in 73mm and 73.5mm, along with the SUPERTECH cylinder head range. Forged connecting rods, however, are not listed here.
The HONDA 2.0 turbo K20C1 of the Civic X Type-R 306HP is served here by two families of parts. Forged connecting rods are offered by BOOSTLINE, whose three-pocket I-beam saves weight without losing stiffness, and by WÖSSNER, whose version uses a conventional I-beam. The choice comes down to the power target and the budget, both ranges being supplied complete with their bolts. ACL RACE and KING RACING thrust washers complete the page. No forged pistons are listed here.
This page covers the HONDA 2.0 turbo K20C1 of the Civic X Type-R FK8 310HP. What separates the two BOOSTLINE forged connecting rods offered here is not the beam, identical three-pocket I-beams, but their bolts: the standard version uses ARP2000 bolts, the uprated version CA625+ bolts, reserved for the most extreme builds. WÖSSNER completes the offer with an I-beam fitted with ARP2000 bolts. ACL RACE and KING RACING thrust washers are also available on this page.
For the HONDA 2.0 turbo K20C1 of the Civic X Type-R FK8 320HP, crankshaft thrust washers are offered in two brands, ACL RACE and KING RACING, both without surface coating: they take up the crankshaft end float and are replaced every time the bottom end is opened. BOOSTLINE and WÖSSNER forged connecting rods complete the page. No forged pistons, no head gasket and no head studs are listed for this version.
Forged pistons Honda Jazz 1.5L L15A Bores 73 73.5mm, CR OEM 9 12.5:1, Pin 18mm. Alloy 2618, ranges JE / Wiseco / Wossner.
Kit of 16 single valve springs with SUPERTECH retainers for HONDA 1.5 i-VTEC L15A L15B LEA:HONDA CIVIC VIII (FD, FA) 1.5 i-VTEC 120hp L15-A7 HONDA CIVIC IX (FB) 1.5 IMA (FB4) 112hp LEA2 HONDA CR-Z (ZF) 1.5 IMA 82, 83, 87, 91, 92, 101hp HONDA CIVIC X Coupé 1.5 170hp L15B7 HONDA CIVIC X Coupé 1.5 177hp L15B7 HONDA CIVIC X Coupé 1.5 Si (FC1) 205hp L15B7
Kit of 8 reinforced ARP connecting rod bolts for the HONDA 1.5 i-VTEC L15A L15B:HONDA CIVIC VIII (FD, FA) 1.5 i-VTEC 120hp L15-A7 HONDA CIVIC X Coupé 1.5 170hp L15B7 HONDA CIVIC X Coupé 1.5 177hp L15B7 HONDA CIVIC X Coupé 1.5 Si (FC1) 205hp L15B7
Reinforced Cometic and Athena head gasket, in multi-layer MLS. Sold individually, one gasket per engine.Brands: Cometic, AthenaEngines: K20C1, K20C4Bore: 86.75 to 88 mm (MLS)Thickness: 0.71 to 1.07 mmReplaces: 12251-RPY-G02
Cometic MLS reinforced gasket, sold individually: one gasket per engine.Brand: CometicEngines: L15B7, L15BA, L15BEBore: 73.5 mmThickness: 0.61 mmReplaces: 12251-59B-004
SUPERTECH 8-valve intake kit for HONDA 1.5 i-VTEC L15A L15B LEA:HONDA CIVIC VIII (FD, FA) 1.5 i-VTEC 120hp L15-A7HONDA CIVIC IX (FB) 1.5 IMA (FB4) 112hp LEA2HONDA CR-Z (ZF) 1.5 IMA 82hp 83hp 87hp 91hp 92hp 101hpHONDA CIVIC X Coupé 1.5 170hp L15B7HONDA CIVIC X Coupé 1.5 177hp L15B7HONDA CIVIC X Coupé 1.5 Si (FC1) 205hp L15B7
Set of 8 SUPERTECH exhaust valves for HONDA 1.5 i-VTEC L15A L15B LEA:HONDA CIVIC VIII (FD, FA) 1.5 i-VTEC 120hp L15-A7 HONDA CIVIC IX (FB) 1.5 IMA (FB4) 112hp LEA2 HONDA CR-Z (ZF) 1.5 IMA 82hp, 83hp, 87hp, 91hp, 92hp, 101hp HONDA CIVIC X Coupé 1.5 170hp L15B7 HONDA CIVIC X Coupé 1.5 177hp L15B7 HONDA CIVIC X Coupé 1.5 Si (FC1) 205hp L15B7
Set of 32 SUPERTECH valve collets for 5.5mm valves: Choice of keeper grooves Reference: KPR-5.5-7A-ST-32 Fits Honda F20C, D16Z6, D16Y8, D16Y6, D16Y7, D15B, D17A, H22A VTEC, CR-Z, LEA, L15A, F22C, K20A4, K24Z7 DOHC VTEC, K20C1, B16A, B17A, R18A SOHC I-VTEC, K24A2, K20A2, K20A3, K20Z1, K20Z3, K24Z1, K24Z3; Acura B18C5, B18C1, K24A2, K24Z7 DOHC VTEC, B16A,...
Set of 8 SUPERTECH 5.5mm valve stem seals for the exhaust valves, HONDA. Exhaust side only: the intake valve version is a separate item.Fitment (engine code): 1.5L 16v - L15A LEA; 1.6L 16v - B16A; 1.7L 16v - B17A; 1.7L 16v - D17; 1.8L 16v - B18C1; 1.8L 16v - B18C5; 2.0L 16v - F20C; 2.0L 16v - K20A/Z; 2.2L 16v - F22C; 2.2L 16v - H22; 2.4L 16v - K24; 1.6L...
Set of 8 SUPERTECH valve stem seals 5.5mm for the INTAKE valves of HONDA L15 B16 B17 D16 D17 B18 F20 F22 H22 K20 K24 R18Fits Honda 1.5L 16v L15A LEA, 1.6L 16v B16A, 1.7L 16v B17A, 1.7L 16v D17, 1.8L 16v B18C1, 1.8L 16v B18C5, 2.0L 16v F20C, 2.0L 16v K20A/Z, 2.2L 16v F22C, 2.2L 16v H22, 2.4L 16v K24, 1.6L 16v D16Z, 1.6L 16v D16Y7, 1.6L 16v D16Y8, 1.8L 16v...
Set of ACL RACE / KING RACING thrust washers for HONDA 1.5 1.6 1.8 2.0 2.2 2.3 2.4 engines
Set of 8 trimetal connecting rod half-bearings for the Honda K20 and K24.Brands and treatments: ACL Race, ACL Calico and King Racing XPC Compatibility: Civic Type R, Integra Type R, Accord, CR-V, Element, Odyssey Engine codes: K20A2, K20Z1, K20C1, K24A1, K24A3, K24A4, K24A8, K24Z1 Available sizes: standard to +0.50 mm, increased-clearance versions (HX,...
kit 16 half-moons / keys for SUPERTECH valves-diameter 5.5mm:Number of groove(s) to choose fromReference:-KPR-5.5-7A-ST-16
The HONDA Civic X (since 2016) covers here the 1.8 R18Z1 of the FC6 and FK5, the 1.5 L15B7 of the Coupé in 170, 177 and 205hp Si (FC1), and the 2.0 Type R K20C1 of the FK8.
