BMW Z4 G29

Manufacturers

BMW Z4 G29

BMW Z4 G29

BMW Z4 G29

There are 25 products.

Subcategories

  • BMW Z4 20i G29 163/197hp B48B20B 2018-
    BMW Z4 20i G29 163/197hp B48B20B 2018-

    The Z4 20i G29 runs the B48B20B, BMW's modular 2.0 16V turbo four-cylinder, rated at 163 and 197hp in this roadster.

    The rotating assembly is the core of this page: forged JE PISTONS, WÖSSNER and SUPERTECH pistons from 82 to 83mm bore, 9.5:1 to 11:1, with a 22mm gudgeon pin and a 33.2mm compression height; forged 4340 steel ZRP and BOOSTLINE connecting rods supplied with ARP2000, L19 or CA625+ bolts; tri-metal ACL RACE big end bearings in standard size, HX extra clearance, +0.025 and +0.25mm.

    SUPERTECH covers the cylinder head: standard size valves, springs with retainers, valve stem seals and 5 and 6mm collets.

  • BMW Z4 30i G29 258hp B48B20B 2018-
    BMW Z4 30i G29 258hp B48B20B 2018-

    The Z4 30i G29 carries the same B48B20B as the 20i, here rated at 258hp: both versions of the roadster share exactly the same uprated stock.

    This page details the cylinder head. SUPERTECH supplies the set of 8 intake valves and the set of 8 exhaust valves in standard size, the 16 uprated springs with their retainers, the intake and exhaust valve stem seals, and the 5 and 6mm collets in one or three grooves.

    The rotating assembly completes the picture: forged JE PISTONS, WÖSSNER and SUPERTECH pistons, 4340 steel ZRP and BOOSTLINE connecting rods, tri-metal ACL RACE big end bearings.

  • BMW Z4 M40i G29 340hp B58B30C 2018-
    BMW Z4 M40i G29 340hp B58B30C 2018-

    The Z4 M40i G29 is powered by the B58B30C, a 340hp 3.0 24V turbo straight-six shared with the TOYOTA Supra.

    Two sets of forged pistons cover 82 to 83mm bore at 10.5:1 and 11:1, in the JE PISTONS, JE Ultra Series, WÖSSNER and DIAMOND ranges, one of them drawn for a 100mm stroke crankshaft. The forged ZRP and BOOSTLINE connecting rods come in sixes, with ARP2000, L19 or CA625+ bolts. The head gasket is either an ATHENA O-ring in 83.0 and 84.5mm at 1.00mm or a COMETIC MLX in 83.0mm at 0.91mm, with ARP head studs and a set of 14 ARP 8740 main studs.

    Big end and main bearings come from ACL RACE and KING RACING pMaxKote, the valve train from SUPERTECH.

Showing 1 - 25 of 25 items
BMW Z4 G29

The BMW Z4 G29 page gathers uprated engine parts for the G29 roadster, built from 2018. Three engine versions are covered:

  • Z4 20i, B48B20B turbo four-cylinder, 163hp and 197hp;
  • Z4 30i, B48B20B, 258hp;
  • Z4 M40i, B58B30C turbo straight-six, 340hp.

Beyond the sub-categories, the page carries twenty-five parts directly for the B48 and B58 blocks: forged pistons and connecting rods, intake and exhaust valves, valve springs, valve stem seals, SUPERTECH and FERREA collets, tri-metal big end and main bearings, an uprated head gasket, ARP head studs and main studs.
