BMW 525i E34 170hp M20B25 1988-1990
Manufacturers
BMW 525i E34 170hp M20B25 1988-1990
Set of 6 forged 4340-steel connecting rods for BMW 6-cylinder, 135 mm c-to-c.Brands: ZRP Compatibility: 325i E30, 328i E36, 330i E46, M3 E36 US Engine codes: M20B25, M50B25 no VANOS, M52B28, M54B30, S50B30 US, S52B32 US Bolts: ARP 2000 or L19
Wiseco & Wiseco AP forged piston kit for BMW M20B25: bores 84-85 mm, RV 8.8 or 11.5-11.6:1, pin 22 mm, dome ⌀8.3 to +14.6 cc, rings included.
Wiseco AP Forged Pistons for M20 2.7L Stroker: Bore 84-85mm, RV 8.5 or 10:1, Pin 22mm, CH 31.2mm, Dome ⌀11.1/?1.6cc, Rings Included.
Kit of 12 ARP2000 rod bolts replacing the original bolts on the OEM rods of BMW inline-six M50 / M50TU and M20B25 engines.Brand: ARP Engines: M20B25, M50B20 / M50B20TU, M50B25 / M50B25TU Dimensions: M9 x 53 mm Grade: ARP2000
Kit of 14 ARP2000 cylinder head studs for BMW 325i, 325iX, 525i and Z1 (M20B25).Brand: ARP Engines: M20B25 Thread: M10 x 1.5 Grade: ARP2000
Reinforced Athena (O-Ring) and Cometic (MLS) head gaskets. Sold individually, one gasket per engine.Brands: Athena, CometicEngines: M20B25, M20B27Bore: 85 to 86.5 mmThicknesses: 0.69 to 3.56 mmReplaces: 11 12 1 722 734
Kit 6 reinforced exhaust valves SUPERTECH for BMW 2.5 12V M20B25 engine:BMW 325i E30 1983 - 1993BMW 525i E34 1988 - 1990References: BMEVN-1084, BMEVI-1085.
Kit 6 reinforced intake valves SUPERTECH for BMW 2.5 12V M20B25 engine:BMW 325i E30 1983 - 1993BMW 525i E34 1988 - 1990References: BMIVN-1084, BMIVN-1085.Intake valves only; the reinforced exhaust valves are listed separately.
Kit of 24 half-moon valve collets for SUPERTECH / FERREA valves, 7mm diameter:Number of grooves of your choiceReferences: KPR-VW7-T-24, KPR-VW7-S-24
Tri-metal main bearings ACL RACE / KING RACING for BMW M20B25, M50B20/B25, M52B25/B28, M54B25/B30, S50B30/B32, S54B32:BMW 325i E30 1983-1993 BMW 320i 323i 325i M3 E36 1991-2000 BMW 323i 325i 330i M3 E46 1998-2006 BMW 520i 525i E34 1988-1996 BMW 523i 525i 530i E39 1996-2004 BMW 525i 530i E60 2001-2010 BMW Z3 Z4 2.0 3.0 Z3M Z4M E36 E85 1999-2008
Set of 12 trimetal connecting rod half-bearings for BMW inline-six M20, M50, M52 and M54.Brands and treatments: ACL Race and King Racing (optional pMaxKote coating) Compatibility: E30, E34, E36, E39, E46, E60, Z3, Z4 Engine codes: M20, M50, M52, M54, S50B30US, S52B32US Available sizes: standard to +0.50 mm, increased-clearance versions (HX / STDX)
KENT CAMS vernier cam pulley for BMW M20B25 2.5 12V engine:BMW 325 i E30 1983 - 1993 BMW 525 i E34 1988 - 1990
Vernier cam pulleys CATCAMS / KENT CAMS for the BMW 2.5 12V M20B25 engine:BMW 325 i E30 1983 - 1993 BMW 525 i E34 1988 - 1990
The M20B25 is the only belt-driven 12-valve engine of the BMW 5 Series E34 range, and this page gathers what we hold for it. Forged pistons come in WISECO, WISECO AP and WOSSNER from 84 to 85mm and 8.8:1 to 11.6:1, with a second WISECO AP set intended for a build using the longer-stroke M20B27 crankshaft, at 8.5:1 and 10:1. ZRP forged rods measure 135mm centre to centre. The head takes SUPERTECH intake and exhaust valves, SUPERTECH 7mm collets, a COMETIC MLS gasket in 85.0mm or an ATHENA O-ring at 85.5mm, and ARP head studs. Vernier cam pulleys are available in KENT CAMS and CATCAMS.
