Gasket Cylinder head reinforced TOYOTA G16E-GTS Yaris GR

We offer you here several reinforced Cylinder head Gaskets forTOYOTA G16E-GTS Yaris GRbrandedATHENAthe technical characteristics of which you will find below.

The choice of Cylinder head Gasket is made via the drop-down menus located just below the price, by simply selecting the thickness of Gasket and the type of Gasket you want.

Find below the link (click on the image) of the Cylinder head studs / screws compatible with your engineTOYOTA G16E-GTS Yaris GR:

For information, here are the technical characteristics of the original Gasket

• Motor bore: 77mm
• Thickness: 0.90mm

Technical characteristics

• Motor bore: up to 92.20mm
• Thickness(es) to choose from: 1.00mm
• Gasket Type: O-RING
• References: 330189R

Designed and manufactured in Italy, the reinforced Cylinder head Gaskets from the Athena brand are available in two forms:

• MLS:these Gasketsare made up of several sheets of stainless steel superimposed and riveted together. The stainless steel sheets are laser cut for increased precision and receive an elastomer-based surface treatment (NBR or FKM). In order to obtain optimal sealing, the contours of the cylinders and water and oil passages are stamped/embossed. Forthe most extreme applications, reinforcement at the level of the cylinders is added.
• O-Ring:these GasketsConsist of a steel sheet covered with asbestos-free aramid fiber and an AISI 304 stainless steel ring(at the cylinder level). A bead of silicone applied to critical points (water and oil passages) ensures maximum sealing of the Cylinder head Gasket. This type of Gasket is mandatory for heavily supercharged engines.
