1.8L 16v - CA18DET
Manufacturers
1.8L 16v - CA18DET
Warning: Last items in stock!
New product
Forged pistons Nissan CA18DET 1.8L 16v Bores 83-84.5mm, Compression ratio 8.0-9.2:1. Ranges JE FSR, Wiseco, Wossner, Supertech.
Compatibilities 200SX S13, 180SX, Silvia S12/S13, Bluebird RNU12.
Characteristics of the forged pistons offered by NSB Concept for Nissan CA18DET 1.8L 16V:
| ReferencePiston | Bore (mm) | VR | Axis (mm) | Axis Height (mm) | Range | Aluminum | Treatment | Forging | Dome (cc) | Weight (g) | Segments |
|---|---|---|---|---|---|---|---|---|---|---|---|
| K9197DA | 83 | 8:1 | 20 | 30 | Wossner | N/A | N/A | Round | -4.4 | N/A | 830XTY |
| JE-302299 | 83 | 8.5:1 | 20 | 30 | JE FSR | 2618 | N/A | FSR | -0.5 FT | 292 | N/A |
| WK630M83 | 83 | 8.5:1 | 20 | 29.75 | Wiseco | 2618 | Skirt | N/A | -0.5 FT | N/A | 8300XX |
| K9431DA | 83 | 9:1 | 20 | 30 | Wossner | N/A | N/A | Round | 3.8 | N/A | 830XTY |
| K9197D050 | 83.5 | 8.1:1 | 20 | 30 | Wossner | N/A | N/A | Round | -4.4 | N/A | 835XTY |
| JE-302300 | 83.5 | 8.5:1 | 20 | 30 | JE FSR | 2618 | N/A | FSR | -0.5 FT | 296 | N/A |
| P4-NCA18-835-CR8.5-H13-4 | 83.5 | 8.5:1 | 20 | 30 | Supertech | N/A | Head + Skirt | N/A | -0.9 | N/A | W8350XX |
| WK630M835 | 83.5 | 8.5:1 | 20 | 29.75 | Wiseco | 2618 | Skirt | N/A | -0.5 FT | N/A | 8350XX |
| K9431D050 | 83.5 | 9.1:1 | 20 | 30 | Wossner | N/A | N/A | Round | 3.8 | N/A | 835XTY |
| K9197D100 | 84 | 8.2:1 | 20 | 30 | Wossner | N/A | N/A | Round | -4.4 | N/A | 840XTY |
| JE-302301 | 84 | 8.5:1 | 20 | 30 | JE FSR | 2618 | N/A | FSR | -0.5 FT | 300 | N/A |
| P4-NCA18-84-CR8.5-H13-4 | 84 | 8.5:1 | 20 | 30 | Supertech | N/A | Head + Skirt | N/A | -0.1 | N/A | W8400XX |
| WK630M84 | 84 | 8.5:1 | 20 | 29.75 | Wiseco | 2618 | Skirt | N/A | -0.5 FT | N/A | 8400XX |
| K9431D100 | 84 | 9.2:1 | 20 | 30 | Wossner | N/A | N/A | Round | 3.8 | N/A | 840XTY |
| P4-NCA18-84.5-CR8.5-H13-4 | 84.5 | 8.5:1 | 20 | 30 | Supertech | N/A | Head + Skirt | N/A | -0.11 | N/A | W8450XX |
| P4-NSR20-86.5-CR10-4 | 86.5 | 10.1:1 | 22 | 32 | Supertech | N/A | Head + Skirt | N/A | -4 | N/A | W8650XX |
Engine compatibility:
1.8L 16v CA18DET
| Brand | Model | Chassis | Engine Code | Power (hp) | Years |
|---|---|---|---|---|---|
| Nissan | 180SX | RS13 | CA18DET | 175 | 1989 1991 |
| Nissan | 200SX (S13) | RS13 | CA18DET | 169 | 1989 1994 |
| Nissan | Bluebird SSS ATTESA | RNU12 | CA18DET | 175 | 1987 1989 |
| Nissan | Silvia RS-X | S12 | CA18DET | 175 | 1987 1988 |
| Nissan | Silvia (S13) | S13 | CA18DET | 175 | 1988 1990 |
Piston Manufacturer Reference (OEM):
Original Nissan pistons (PISTON W/PIN) and ring sets for the vehicles listed:
| Reference | Size | Details | Applications (vehicles in the table) |
|---|---|---|---|
| 12010-44F01 | STD(83.0) | Piston & pin assembled | 200SX S13 1989.1994, 180SX RS13 1989.1991, Silvia S13 1988.1990 |
| 12010-44F02 | OS +0.50 (83.5) | Piston & pin assembled | 200SX S13 1989.1994, 180SX RS13 1989.1991, Silvia S13 1988.1990 |
| 12033-44F02 | STD(83.0) | Ring set (4 pistons) | CA18DE/CA18DET applications above |
| 12010-56E65 ~ 56E69 | STD (grades 1-5) | Piston & pin assembled | Silvia S12 RS-X 1987.1988 (CA18DET) |
| 12010-56E22 / 56E23 | OS +0.50 / +1.00 | Piston & pin assembled | Silvia S12 RS-X 1987.1988 (CA18DET) |
Warning:
before any assembly, please check the integrity and conformity of each component of the piston kit as well as the conformity of the assembly in the engine; any possible warranty is strictly limited to the parts of the piston kit only.
