2.0L 8v - Pinto
Manufacturers
2.0L 8v - Pinto
Warning: Last items in stock!
New product
Ford 2.0 OHC?Pinto forged pistons bores 90.9-97.03 mm, RV 9-12.5:1, axle 24 mm. JE, Wiseco, Wossner ranges. Applications: Capri, Cortina/Taunus, Sierra, Granada, Escort RS2000, P100.
Specifications of the forged pistons offered by NSB Concept for Ford 2.0 L 8 v OHC « Pinto » :
| Reference piston | Bore (mm)OEM 91,5 | CROEM 9,2 :1 | pin (mm)OEM 24 | Height pin (mm)OEM 41,6 | Range | Aluminium | Coating | Forging | Dome (cc) | Weight (g) | Rings |
|---|---|---|---|---|---|---|---|---|---|---|---|
| K9232D010 | 90,9 | 12 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 910XSY |
| K9392D010 | 90,9 | 12 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 910XSY |
| WKE221M9094 | 90,94 | 9,2 :1 | 24 | 41,6 | Wiseco | 4032 | Skirt | NC | 0 | NC | 9100XX |
| K9232D020 | 91 | 12 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 910XSY |
| K9392D020 | 91 | 12 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 910XSY |
| K9232D045 | 91,25 | 12,1 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 912XSY |
| K9392D045 | 91,25 | 12,1 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 912XSY |
| WKE221M915 | 91,5 | 9,2 :1 | 24 | 41,6 | Wiseco | 4032 | Skirt | NC | 0 | NC | 9150XX |
| K9232D070 | 91,5 | 12,2 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 915XSY |
| K9392D070 | 91,5 | 12,2 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 915XSY |
| WKE221M92 | 92 | 9,2 :1 | 24 | 41,6 | Wiseco | 4032 | Skirt | NC | 0 | NC | 9200XX |
| K9232D120 | 92 | 12,3 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 920XSY |
| K9392D120 | 92 | 12,3 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 920XSY |
| WKE221M9225 | 92,25 | 9,2 :1 | 24 | 41,6 | Wiseco | NC | Skirt | NC | 0 | NC | 9225XX |
| K9232D170 | 92,5 | 12,4 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 925XSY |
| K9392D170 | 92,5 | 12,4 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 925XSY |
| WKE221M9275 | 92,75 | 9,2 :1 | 24 | 41,6 | Wiseco | NC | Skirt | NC | 0 | NC | 9275XX |
| WKE221M93 | 93 | 9,2 :1 | 24 | 41,6 | Wiseco | 4032 | Skirt | NC | 0 | NC | 9300XX |
| K9232D220 | 93 | 12,5 :1 | 24 | 41,65 | Wossner | NC | NC | Round | 0 | NC | 930XSY |
| K9392D220 | 93 | 12,5 :1 | 24 | 34,15 | Wossner | NC | NC | Round | 0 | NC | 930XSY |
| WKE221M935 | 93,5 | 9,2 :1 | 24 | 41,6 | Wiseco | 4032 | Skirt | NC | 0 | NC | 9350XX |
| WKE221M94 | 94 | 9,2 :1 | 24 | 41,6 | Wiseco | 4032 | Skirt | NC | 0 | NC | 9400XX |
| JE-118558 | 96,52 | 9 :1 | 23,55 | 27,69 | JE Round | 2618 | NC | Round | -2 | 341 | J10004-3810-5 |
| WK157A3 | 96,52 | 10 :1 | 23,55 | 27,69 | Wiseco | 4032 | Skirt | NC | -3,4 | NC | 3810A(4x) |
| JE-118560 | 97,03 | 9 :1 | 23,55 | 27,69 | JE Round | 2618 | NC | Round | -2 | 349 | J10004-3820-5 |
| WK157A4 | 97,03 | 10 :1 | 23,55 | 27,69 | Wiseco | 4032 | Skirt | NC | -3,4 | NC | 3820B(4x) |
Compatibility engine :
| Brand | Model | Chassis | Engine code | Power (ch) | Years |
|---|---|---|---|---|---|
| Ford | Capri Mk2 | Capri Mk2 | NEE/NEN (2.0 OHC) | 101 | 1974–1978 |
| Ford | Capri Mk3 | Capri Mk3 | NEE/NEN (2.0 OHC) | 101 | 1978–1986 |
| Ford | Cortina/Taunus TC1 | TC1 | NEG/NER (2.0 OHC) | 98–101 | 1970–1976 |
| Ford | Cortina/Taunus TC2 | TC2 | NEG/NER (2.0 OHC) | 101 | 1976–1982 |
| Ford | Escort RS2000 Mk1/Mk2 | Mk1/Mk2 | NEA/NE (2.0 OHC) | 100–110 | 1973–1980 |
| Ford | Granada Mk2 | Granada Mk2 | NEB/NEH/NEK (2.0 OHC) | 101–105 | 1977–1985 |
| Ford | P100 (Sierra pickup) | P100 (Sierra) | 2.0 OHC | 74 | 1988–1993 |
| Ford | Sierra Mk1 | Sierra Mk1 | NES/Nand/NEJ/NE5 (2.0 OHC) | 105–115 | 1982–1992 |
Warning : Before installation, please verify the integrity and conformity of each component of the piston kit, as well as the correctness of the assembly in the engine. Any warranty is strictly limited to the parts included in the piston kit.
