JE forged pistons for PSA 1.6 8v TU5J2 (Pin 19.5): Bores 78.5-79.0 mm, Volume ratio 9.0-11.8:1, CH 32.5. compatible 106 XSi & 106 Rally. FULL TABLE + OEM INFO.
Specifications of the forged pistons offered by NSB Concept for Peugeot/Citroën 1.6 L 8v TU5J2 (pin 19,5 mm) :
| Reference | OEM Bore 78,50 mm | OEM CR 10,2 :1 | OEM Pin 19,50 mm | Height OEM Pin 32,5 mm | Range | Coating | Aluminium | Forging | Dome | Weight | Rings |
|---|---|---|---|---|---|---|---|---|---|---|---|
| JE-344093C*4 | 78.50 | 9:1 | 19.48 | 32.50 | JE | NC | NC | NC | -10.5 | NC | NC |
| JE-336844C*4 | 78.50 | 11.8:1 | 19.48 | 32.50 | JE | NC | NC | NC | 2.5 | NC | NC |
| JE-349743C*4 | 79.00 | 9:1 | 19.48 | 32.50 | JE | NC | NC | NC | -10.5 | NC | NC |
| JE-336094C*4 | 79.00 | 11.8:1 | 19.48 | 32.50 | JE | NC | NC | NC | 2.5 | NC | NC |
Compatibility (engine codes):
Original vehicles equipped with the engine TU5J2 1.6 8v :
| Brand | Model | Engine code | Power | Years |
|---|---|---|---|---|
| Peugeot | 106 Rallye (Phase 2) | TU5J2 (NFW) | 103 hp | 1997 – 2000 |
| Peugeot | 106 XSi | TU5J2 (NFY) | 103 hp | 1994 – 1996 |
Manufacturer piston references (OEM) :
Warning: Before installation, please verify the integrity and conformity of each component of the piston kit as well as the correctness of the assembly in the engine; any warranty is strictly limited to the parts included in the piston kit.
