Reduced price! Pistons forgés 2.5L 8v M44 Porsche View larger

Forged pistons 2.5L 8v M44 Porsche

New product

Forged pistons Porsche M44 2.5 8v: diameter 100-101 mm, pin 24 mm, Pin Height 40.80 mm, CR 7.5-10.8:1. compatible 944, 924S and 944 Turbo 8v. Complete table + OEM references.

More details

1 305,40 € tax incl.

-25%

1 740,53 € tax incl.

ORDER TODAY, WE SHIP IN 5 - 15 DAYS

  • Specifications of the forged pistons offered by NSB Concept for Porsche 2.5 L 8 V M44 (944 / 924S, as well as 944 Turbo 8v) :

    ReferenceOEM Bore
    100,00 mm    		OEM CR 9,5–10,2 :1 (NA) / 8,0 :1 (Turbo)OEM Pin
    24 mm    		Height OEM Pin
    40,80 mm    		RangeCoatingAluminiumForgingDomeWeightRings
    WKE538M100100.08:12440.8WisecoSkirtNCNC-25.7NC10000XX
    K9477DA100.08:12440.8WossnerNCNCRound-26.6NC1000XPY
    K9476DA100.010.6:12440.8WossnerNCNCRound-0.5NC1000XPY
    JE-293449C*4100.57.5:12440.75JENCNCNC-28.4NCNC
    K9477D050100.58.1:12440.8WossnerNCNCRound-26.6NC1005XPY
    K9476D050100.510.7:12440.8WossnerNCNCRound-0.5NC1005XPY
    K9477D100101.08.1:12440.8WossnerNCNCRound-26.6NC1010XPY
    K9476D100101.010.8:12440.8WossnerNCNCRound-0.5NC1010XPY


    Compatibility (engine codes):

    • M44/01 – M44/06 : 944 2.5 8v (1982–1986, naturally aspirated).
    • M44/07 – M44/10 : 944 & 924S 2.5 8v (1987–1988, naturally aspirated depending on market/gearbox).
    • M44/51 – M44/52 : 944 Turbo 2.5 8v (1986–1991).


    Original vehicles equipped with the M44 2.5 8v :

    BrandModelEngine codePowerYears
    Porsche924S 2.5M44/07150 hp1986 – 1987
    Porsche924S 2.5M44/09 / M44/10160 hp1988
    Porsche944 2.5 (NA)M44/01 – M44/06163 hp (UE)1982 – 1987
    Porsche944 2.5 (NA)M44/07 – M44/09160 hp (UE)1988
    Porsche944 Turbo (951)M44/51220 hp1985 – 1988
    Porsche944 Turbo S / TurboM44/52250 hp1988 – 1991


    OEM piston references :

    • 944 / 924S 2.5 NA (M44/01–06, /07–10): piston 944.103.091.07 (ordered by class/diameter; replaces 944.103.091.01/.02/… depending on model year). Ring sets: 944.103.902.82 / 944.103.902.83 (Ø 100 mm).
      944 Turbo 2.5 8v (M44/51, /52): piston 951.103.091.01; ring set 951.103.901.02 (Ø 100 mm).
      Important: the exact references depend on the VIN, the selection class A/B/C and the oversizes. Verification mandatory in the Porsche Catalog.

    Warning: Before installation, please verify the integrity and conformity of each component of the piston kit as well as the correctness of the assembly in the engine; any warranty is strictly limited to the parts included in the piston kit.
