3.5L 24v - S38B36
Manufacturers
3.5L 24v - S38B36
Warning: Last items in stock!
New product
BMW S38B36 3.6L forged pistons bores 94-95 mm, RV 8.0-12.2:1, axle 22 mm. Wiseco low, mid or high compression range. Specs tables, M5 E34 compatibility, OEM reference included.
Specifications of the forged pistons offered by NSB Concept for BMW 3.6 L 24 v S38B36 :
| Reference piston | Bore (mm)OEM 94,00 | CROEM 10,0 :1 | pin (mm)OEM 22 | Height pin (mm)OEM 30,22 | Range | Aluminium | Coating | Forging | Dome (cc) | Weight (g) | Rings |
|---|---|---|---|---|---|---|---|---|---|---|---|
| WKE242M94 | 94 | 12:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -6,0 | NC | 9400XX |
| WKE240M94 | 94 | 8:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -38,0 | NC | 9400XX |
| WKE241M94 | 94 | 9,4:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -24,0 | NC | 9400XX |
| WKE242M9425 | 94,25 | 12:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -6,0 | NC | 9425XX |
| WKE240M9425 | 94,25 | 8:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -38,0 | NC | 9425XX |
| WKE241M9425 | 94,25 | 9,4:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -24,0 | NC | 9425XX |
| WKE242M945 | 94,5 | 12,2:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -6,0 | NC | 9450XX |
| WKE240M945 | 94,5 | 8:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -38,0 | NC | 9450XX |
| WKE241M945 | 94,5 | 9,4:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -24,0 | NC | 9450XX |
| WKE242M95 | 95 | 12,2:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -6,0 | NC | 9500XX |
| WKE240M95 | 95 | 8:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -38,0 | NC | 9500XX |
| WKE241M95 | 95 | 9,4:1 | 22 | 30,22 | Wiseco | NC | Skirt | NC | -24,0 | NC | 9500XX |
Compatibility engine :
| Brand | Model | Chassis | Power (ch) | Years |
|---|---|---|---|---|
| BMW | M5 3.6 | E34 | 315 | 1988 – 1992 |
Reference piston manufacturer (OEM):
