Forged Pistons 2.0L 16v K20A K20Z Honda

Marque Forged Pistons

Condition: New product

Forged pistonsHonda K20A/K20Z 2.0L Bores86 90mm, CR OEM9 12.5:1, Pin22mm. Ranges:JE FSR, JE Round, JE Ultra Series, Manley, Supertech, Wiseco, Wiseco AP, Wossner. COMPLETE technical sheet, compatibilities and Pistons Origine references.

More details

574,43 € tax incl.

-25%

765,91 € tax incl.

Bore | CR | Range

ORDER TODAY, WE SHIP IN 5 - 15 DAYS

Quantity

More info
Avis (0)

Specifications of the forged pistons offered by NSB Concept for Honda 2.0 L 16 v K20A / K20Z :

Reference piston	Bore (mm)OEM 86	CROEM 9 :1	pin (mm)OEM 22	Height pin (mm)OEM 30	Range	Aluminium	Coating	Forging	Dome (cc)	Weight (g)	Rings
JE-296963	86	9 :1	22	29,87	JE FSR	2618	NC	FSR	-4,7	303	NC
610000-4	86	9 :1	NC	30	Manley	4032	Skirt	NC	-6,5	319	NC
P4-HK86-N6R-4	86	9 :1	22	30	Supertech	NC	Crown + Skirt	NC	-6	NC	W8600XX
WK568M86	86	9 :1	22	30	Wiseco	2618	Skirt	NC	-9	NC	8600XX
K9244DA	86	9 :1	22	30	Wossner	NC	NC	Round	-7,63	NC	860XSY
K9565DA	86	9 :1	22	30	Wossner	NC	NC	Slipper	-9	NC	GNH86.00
K9566DA	86	9,5 :1	22	30	Wossner	NC	NC	Slipper	-3,2	NC	GNH86.00
WK631M86	86	9,8 :1	22	30	Wiseco	2618	Skirt	NC	-3.5 FT	NC	8600XX
JE-309411	86	10 :1	22	29,87	JE FSR	2618	NC	FSR	2,3	323	NC
JE-361270	86	10 :1	22	29,87	JE Ultra Series	2618	Crown + Skirt	FSR	0,73	346	NC
JE-204256	86	11 :1	22	29,87	JE Round	2618	NC	Round	7,1	307	NC
K9567DA	86	11 :1	22	30	Wossner	NC	NC	Slipper	5	NC	GNH86.00
P4-HK86-P6-4	86	11,2 :1	22	30	Supertech	4032	Crown + Skirt	NC	6,5	304	W8600XX
JE-226379	86	11,3 :1	22	29,87	JE Round	2618	NC	Round	9,2	313	NC
610100-4	86	11,5 :1	NC	30	Manley	4032	Skirt	NC	8,4	324	NC
P4-HK86-P8-4	86	11,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	8	306	W8600XX
JE-338057	86	11,6 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
WK573M86	86	11,7 :1	22	30	Wiseco	NC	Skirt	NC	8	NC	8600XX
WK573M86AP	86	11,7 :1	22	30	Wiseco AP	2618	Skirt	NC	8	NC	8600XX
P4-HK86-P11-4	86	12 :1	22	30	Supertech	4032	Crown + Skirt	NC	11	314	W8600XX
K9088DA	86	12 :1	22	30	Wossner	NC	NC	Slipper	9	NC	GNH86.00
K9243DA	86	12,3 :1	22	27	Wossner	NC	NC	NC	8,25	NC	860XDS
WK650M86	86	12,4 :1	22	30	Wiseco	2618	Skirt	NC	10,5	NC	8600XX
WK650M86AP	86	12,4 :1	22	30	Wiseco AP	2618	Skirt	NC	10,5	NC	8600XX
JE-361255	86	12,5 :1	22	29,87	JE FSR	2618	NC	FSR	12,4	329	NC
610200-4	86	12,5 :1	NC	30	Manley	4032	Skirt	NC	12,5	329	NC
P4-HK86-P15-4	86	12,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	11,4	296	W8600XX
JE-361252	86,25	9,3 :1	22	29,87	JE FSR	2618	NC	FSR	-4,9	304	NC
JE-361271	86,25	10 :1	22	29,87	JE Ultra Series	2618	Crown + Skirt	FSR	0,4	348	NC
JE-361253	86,25	10,3 :1	22	29,87	JE FSR	2618	NC	FSR	2	325	NC
JE-361254	86,25	11,6 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
JE-361256	86,25	12,5 :1	22	29,88	JE FSR	2618	NC	FSR	12,4	331	NC
JE-296964	86,5	9 :1	22	29,87	JE FSR	2618	NC	FSR	-5,3	308	NC
P4-HK8650-N6-4	86,5	9 :1	22	30	Supertech	4032	Crown + Skirt	NC	-6	281	W8650XX
WK568M865	86,5	9 :1	22	30	Wiseco	2618	Skirt	NC	-9	NC	8650XX
K9244D050	86,5	9,1 :1	22	30	Wossner	NC	NC	Round	-7,63	NC	865XSY
K9565D050	86,5	9,1 :1	22	30	Wossner	NC	NC	Slipper	-9	NC	GNH86.50
K9566D050	86,5	9,6 :1	22	30	Wossner	NC	NC	Slipper	-3,2	NC	GNH86.50
WK631M865	86,5	9,8 :1	22	30	Wiseco	2618	Skirt	NC	-3.5 FT	NC	8650XX
JE-309412	86,5	10 :1	22	29,87	JE FSR	2618	NC	FSR	1,8	327	NC
JE-361272	86,5	10 :1	22	29,87	JE Ultra Series	2618	Crown + Skirt	FSR	0,2	350	NC
WK634M865	86,5	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8650XX
K9567D050	86,5	11,1 :1	22	30	Wossner	NC	NC	Slipper	5	NC	GNH86.50
P4-HK865-P6-4	86,5	11,2 :1	22	30	Supertech	NC	Crown + Skirt	NC	6,5	NC	W8650XX
P4-HK8650-P8-4	86,5	11,6 :1	22	30	Supertech	NC	Crown + Skirt	NC	8	NC	W8650XX
JE-338058	86,5	11,7 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
WK573M865	86,5	11,7 :1	22	30	Wiseco	NC	Skirt	NC	8	NC	8650XX
WK573M865AP	86,5	11,7 :1	22	30	Wiseco AP	2618	Skirt	NC	8	NC	8650XX
P4-HK8650-P11-4	86,5	12 :1	22	30	Supertech	4032	Crown + Skirt	NC	11	316	W8650XX
K9088D050	86,5	12,1 :1	22	30	Wossner	NC	NC	Slipper	9	NC	GNH86.50
WK650M865	86,5	12,4 :1	22	30	Wiseco	2618	Skirt	NC	10,5	NC	8650XX
WK650M865AP	86,5	12,4 :1	22	30	Wiseco AP	2618	Skirt	NC	10,5	NC	8650XX
K9243D050	86,5	12,4 :1	22	27	Wossner	NC	NC	NC	8,25	NC	865XSY
JE-361257	86,5	12,5 :1	22	29,89	JE FSR	2618	NC	FSR	12,4	333	NC
P4-HK8650-P15-4	86,5	12,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	11,4	309	W8650XX
JE-309342	87	9 :1	22	29,87	JE FSR	2618	NC	FSR	-5,9	309	NC
WK568M87	87	9 :1	22	30	Wiseco	2618	Skirt	NC	-9	NC	8700XX
K9244D100	87	9 :1	22	30	Wossner	NC	NC	Round	-7,63	NC	870XSY
K9565D100	87	9,2 :1	22	30	Wossner	NC	NC	Slipper	-9	NC	GNH87.00
K9566D100	87	9,7 :1	22	30	Wossner	NC	NC	Slipper	-3,2	NC	GNH87.00
WK631M87	87	9,8 :1	22	30	Wiseco	2618	Skirt	NC	-3.5 FT	NC	8700XX
JE-309413	87	10 :1	22	29,87	JE FSR	2618	NC	FSR	1,2	326	NC
JE-361273	87	10 :1	22	29,87	JE Ultra Series	2618	Crown + Skirt	FSR	-0,4	354	NC
WK634M87	87	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8700XX
K9567D100	87	11,2 :1	22	30	Wossner	NC	NC	Slipper	5	NC	GNH87.00
P4-HK87-N0-4	87	11,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	-0,5	277	W8700XX
P4-HK87-P8-4	87	11,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	8	322	W8700XX
WK573M87	87	11,7 :1	22	30	Wiseco	NC	Skirt	NC	8	NC	8700XX
WK573M87AP	87	11,7 :1	22	30	Wiseco AP	2618	Skirt	NC	8	NC	8700XX
JE-338059	87	11,9 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
K9088D100	87	12,3 :1	22	30	Wossner	NC	NC	Slipper	9	NC	GNH87.00
WK650M87	87	12,4 :1	22	30	Wiseco	2618	Skirt	NC	10,5	NC	8700XX
WK650M87AP	87	12,4 :1	22	30	Wiseco AP	2618	Skirt	NC	10,5	NC	8700XX
JE-345618	87	12,5 :1	22	29,87	JE FSR	2618	NC	FSR	12,4	NC	NC
P4-HK87-P15-4	87	12,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	11,4	325	W8700XX
P4-HK87-P4-4	87	12,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	4,5	308	W8700XX
WK634M8725	87,25	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8725XX
WK568M875	87,5	9 :1	22	30	Wiseco	2618	Skirt	NC	-9	NC	8750XX
K9565D150	87,5	9,3 :1	22	30	Wossner	NC	NC	Slipper	-9	NC	GNH87.50
WK631M875	87,5	9,8 :1	22	30	Wiseco	2618	Skirt	NC	-3.5 FT	NC	8750XX
K9566D150	87,5	9,8 :1	22	30	Wossner	NC	NC	Slipper	-3,2	NC	GNH87.50
JE-361274	87,5	10 :1	22	29,87	JE Ultra Series	2618	Crown + Skirt	FSR	-1	360	NC
WK634M875	87,5	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8750XX
P4-HK875-N0-4	87,5	11,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	-0,5	280	W8750XX
WK573M875	87,5	11,7 :1	22	30	Wiseco	NC	Skirt	NC	8	NC	8750XX
WK573M875AP	87,5	11,7 :1	22	30	Wiseco AP	2618	Skirt	NC	8	NC	8750XX
JE-338060	87,5	12 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
K9088D150	87,5	12,3 :1	22	30	Wossner	NC	NC	Slipper	9	NC	GNH87.50
WK650M875	87,5	12,4 :1	22	30	Wiseco	2618	Skirt	NC	10,5	NC	8750XX
WK650M875AP	87,5	12,4 :1	22	30	Wiseco AP	2618	Skirt	NC	10,5	NC	8750XX
JE-345619	87,5	12,5 :1	22	29,87	JE FSR	2618	NC	FSR	11,9	NC	NC
P4-HK875-P15-4	87,5	12,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	11,4	325	W8750XX
P4-HK875-P4-4	87,5	12,5 :1	22	30	Supertech	4032	Crown + Skirt	NC	4	315	W8750XX
JE-309343	88	9 :1	22	29,87	JE FSR	2618	NC	FSR	-7,2	326	NC
JE-242862	88	9 :1	22	29,87	JE Round	2618	NC	Round	-7,6	325	NC
WK568M88	88	9 :1	22	30	Wiseco	2618	Skirt	NC	-9	NC	8800XX
K9244D200	88	9 :1	22	30	Wossner	NC	NC	Round	-7,63	NC	880XSY
K9565D200	88	9,4 :1	22	30	Wossner	NC	NC	Slipper	-9	NC	GNH88.00
K9566D200	88	9,9 :1	22	30	Wossner	NC	NC	Slipper	-3,2	NC	GNH88.00
JE-309414	88	10 :1	22	29,87	JE FSR	2618	NC	FSR	0	336	NC
JE-361275	88	10 :1	22	29,87	JE Ultra Series	2618	Crown + Skirt	FSR	-1,6	364	NC
WK634M88	88	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8800XX
K9567D200	88	11,3 :1	22	30	Wossner	NC	NC	Slipper	5	NC	GNH88.00
WK573M88	88	11,7 :1	22	30	Wiseco	2618	Skirt	NC	8	NC	8800XX
WK573M88AP	88	11,7 :1	22	30	Wiseco AP	2618	Skirt	NC	8	NC	8800XX
JE-338061	88	12,1 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
K9088D200	88	12,3 :1	22	30	Wossner	NC	NC	Slipper	9	NC	GNH88.00
WK650M88	88	12,4 :1	22	30	Wiseco	2618	Skirt	NC	10,5	NC	8800XX
WK650M88AP	88	12,4 :1	22	30	Wiseco AP	2618	Skirt	NC	10,5	NC	8800XX
JE-345620	88	12,5 :1	22	29,87	JE FSR	2618	NC	FSR	11,5	NC	NC
JE-309344	89	9 :1	22	29,87	JE FSR	2618	NC	FSR	-8,5	329	NC
WK568M89	89	9 :1	22	30	Wiseco	2618	Skirt	NC	-9	NC	8900XX
K9244D300	89	9 :1	22	30	Wossner	NC	NC	Round	-7,63	NC	890XSY
K9565D300	89	9,5 :1	22	30	Wossner	NC	NC	Slipper	-9	NC	GNH89.00
JE-309415	89	10 :1	22	29,87	JE FSR	2618	NC	FSR	-1,1	339	NC
K9566D300	89	10 :1	22	30	Wossner	NC	NC	Slipper	-3,2	NC	GNH89.00
WK634M89	89	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8900XX
K9567D300	89	11,4 :1	22	30	Wossner	NC	NC	Slipper	5	NC	GNH89.00
WK573M89	89	11,7 :1	22	30	Wiseco	2618	Skirt	NC	8	NC	8900XX
WK573M89AP	89	11,7 :1	22	30	Wiseco AP	2618	Skirt	NC	8	NC	8900XX
JE-338062	89	12,3 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC
K9088D300	89	12,3 :1	22	30	Wossner	NC	NC	Slipper	9	NC	GNH89.00
WK650M89	89	12,4 :1	22	30	Wiseco	2618	Skirt	NC	10,5	NC	8900XX
WK650M89AP	89	12,4 :1	22	30	Wiseco AP	2618	Skirt	NC	10,5	NC	8900XX
WK634M895	89,5	11 :1	22	30	Wiseco	2618	Skirt	NC	5	NC	8950XX
JE-317758	90	9 :1	22	29,87	JE FSR	2618	NC	FSR	-10,7	335	NC
K9244D400	90	9 :1	22	30	Wossner	NC	NC	Round	-7,63	NC	900XSY
JE-317757	90	10 :1	22	29,87	JE FSR	2618	NC	FSR	-3,1	353	NC
K9567D400	90	11,5 :1	22	30	Wossner	NC	NC	Slipper	5	NC	GNH90.00
JE-338063	90	12,5 :1	22	29,87	JE FSR	2618	NC	FSR	9	NC	NC

Compatibility engine :

2.0L 16v - K20A/Z

Brand	Model	Chassis	Engine code	Power (ch)	Years
Honda	Civic Type R (EU)	EP3	K20A2	200	2001 – 2005
Honda	Integra Type R (JP)	DC5	K20A	220	2001 – 2006
Honda	Civic Si (US)	FA5/FG2	K20Z3	197	2006 – 2011

Manufacturer piston references (OEM):

Civic Type R 2001–2005 (EP3 – K20A2) — piston Set A (STD) : 13010‑PRB‑A01 ; piston Set B (STD) : 13020‑PRB‑A01.
Integra Type R 2001–2006 (DC5 – K20A) — piston Set A (STD) : 13010‑PRC‑000 ; piston Set A (STD, revision) : 13010‑PRC‑010.
Civic Si 2006–2011 (FA5/FG2 – K20Z3) — piston Set A (STD) : 13010‑PRB‑A01 ; piston Set B (STD) : 13020‑PRB‑A01.

Warning : Before installation, please verify the integrity and conformity of each component of the piston kit, as well as the correctness of the assembly in the engine. Any warranty is strictly limited to the parts included in the piston kit.
