RENAULT Megane 3

RENAULT Megane 3

There are 28 products.

Subcategories

  • RENAULT Megane 3 GT 220hp F4R 874 2012-2016
    RENAULT Megane 3 GT 220hp F4R 874 2012-2016

    The 220hp RENAULT Megane 3 GT, built from 2012 to 2016, uses the turbocharged F4R 874. Eighteen active references, including the TURBOSMART wastegate.

    Rotating assembly: F4RT forged pistons by WISECO at 8.6:1 or WOSSNER from 9 to 9.3:1, bore 82.7 to 84mm, 21mm gudgeon pin; set of 4 ZRP forged con rods in 4340 steel, I-beam, ARP2000 or L19 bolts; ZRP forged crankshaft, stock or 90mm destroke; ACL RACE or KING RACING bearings.

    Head: SUPERTECH valves, CATCAMS or SUPERTECH dual valve springs, ATHENA or COMETIC gasket, ARP2000 studs. VIBRA-TECHNICS mount and NGK spark plugs.

  • RENAULT Megane 3 RS 250hp F4R 874 2009-2015
    RENAULT Megane 3 RS 250hp F4R 874 2009-2015

    The 250hp RENAULT Megane 3 RS, built from 2009 to 2015, uses the F4R 874. Twenty-seven active references, the most complete page of the range.

    Exclusive parts: ROHNCOR Group N engine mounts and torque rods by phase, sets of 4 mounts or single parts, and CATCAMS sport camshafts 5506401 to 5506403.

    Forced induction: TURBOSMART wastegate. Rotating assembly: WISECO or WOSSNER forged pistons, ZRP I-beam con rods, ZRP crankshaft, ACL RACE or KING RACING bearings, ARP fasteners.

    SUPERTECH head parts, ATHENA or COMETIC gasket, NGK spark plugs.

  • RENAULT Megane 3 RS Trophy 265hp F4R 874 2008-2016
    RENAULT Megane 3 RS Trophy 265hp F4R 874 2008-2016

    The 265hp RENAULT Megane 3 RS Trophy, built from 2008 to 2016, uses the F4R 874. Sixteen active references, with no spark plug and no forced induction part.

    Head: 8 SUPERTECH stainless intake valves, OEM or +1.20mm, 8 Inconel exhaust valves, OEM or +1.00mm, CATCAMS or SUPERTECH dual valve springs, 16 SUPERTECH 6mm collets with 1 or 3 grooves, ATHENA or COMETIC gasket, ARP2000 studs.

    Bottom end: WISECO or WOSSNER forged pistons, ZRP con rods, ZRP crankshaft, stock or 90mm destroke, ACL RACE or KING RACING bearings, ARP 8740.

  • RENAULT Megane 3 RS Trophy R 273hp F4R 874 2014-2016
    RENAULT Megane 3 RS Trophy R 273hp F4R 874 2014-2016

    The 273hp RENAULT Megane 3 RS Trophy R, built from 2014 to 2016, uses the F4R 874. Seventeen active references, the common base of the range without wastegate or Group N mounts.

    Bottom end: ZRP forged crankshaft, stock or 90mm destroke, ACL RACE main bearings in standard, standard HX, +0.25mm or +0.50mm, ACL RACE or KING RACING tanged big end bearings, ACL RACE thrust washers in standard or +0.10mm, ARP 8740 main studs, ZRP con rods, WISECO or WOSSNER pistons.

    SUPERTECH head parts, ATHENA or COMETIC gasket, set of 4 NGK IFR7X8G plugs.

Showing 1 - 28 of 28 items
RENAULT Megane 3
RENAULT Megane 3 is the most segmented page of this Renault range: four versions of one and the same F4R 874 turbo block. GT 220hp, RS 250hp, RS Trophy 265hp and RS Trophy R 273hp, from 2008 to 2016. Where the previous generation stopped at 225hp, this block is pushed four steps further and the hardware follows: WISECO and WOSSNER forged pistons at 82.70mm, from 8.6:1 to 9.3:1 depending on target boost, a TURBOSMART TS-0646-1072 wastegate for the RS 250hp, SUPERTECH reinforced valves, NGK spark plugs, nine ROHNCOR mounts, VIBRA-TECHNICS mounts, CATCAMS camshafts, ARP studs, ACL and KING RACING bearings, ZRP forged rods and crankshafts.
