Oil radiator
Manufacturers
Oil radiator
Warning: Last items in stock!
M235L44AN10
New product
BREEZY oil cooler, 235 mm matrix, 44 rows, UNF-JIC 7/8"-14 (DASH10) fittings, black finish. Ref. M235L44AN10.
BREEZY oil cooler, 235 mm matrix, 44 rows, DASH10 fittings, black finish (ref. M235L44AN10).
With its very large matrix, this oil/air cooler offers the highest cooling capacity in the 235 mm range, ideal for heavily loaded engines in motorsport and on track. Its UNF-JIC 7/8"-14 (DASH10) ports connect directly to braided lines, and its standard mounting centres make fitting straightforward. The black finish cuts glare and blends discreetly into the engine bay.
Clearance item at NSB Concept.
| Specifications | |
|---|---|
| Brand | BREEZY |
| Type | Matrix oil cooler (oil/air heat exchanger) |
| Number of rows | 44 |
| Matrix width | 235 mm |
| Thickness | 51 mm |
| Height excl. fittings | 347 mm |
| Overall length | 330 mm |
| Fitting centres | 248 mm |
| Mounting centres | 308 mm |
| Inlet/outlet fittings | UNF-JIC 7/8"-14 (DASH10) |
| Colour | Black |
| Reference | M235L44AN10 |
