2.0L 16v - EA888.1
Fabricants
2.0L 16v - EA888.1
Attention : dernières pièces disponibles !
Neuf
Pistons forgés JE PISTONS/WISECO/WOSSNER/ZRP pour moteur VAG 2.0 TFSI EA888 Gen1 et EA113 axe de piston 21mm
Caractéristiques des pistons forgés proposés par NSB Concept pour VW‑Audi 2.0 L 16 V TFSI EA888 Gen 1 / EA113 (axe 21 mm) :
| Référence (Cliquez) | Alésage mm | RV | Axe mm | Hauteur Axe mm | Gamme | Traitement | Aluminium | Forging | Dôme cc | Poids g | Segments |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DIA-38106-4 | 82.5 | 8.5:1 | 21 | 29.59 | Diamond | Jupe | 2618 | NC | -15.5 | NC | 9513248 |
| DIA-38106-4-H | 82.5 | 8.5:1 | 21 | 29.59 | Diamond HD | Jupe | 2618 | NC | -15.5 | NC | 9513248 |
| DIA-38108-4 | 82.5 | 9:1 | 21 | 29.59 | Diamond | Jupe | 2618 | NC | -11.5 | NC | 9513248 |
| DIA-38108-4-H | 82.5 | 9:1 | 21 | 29.59 | Diamond HD | Jupe | 2618 | NC | -11.5 | NC | 9513248 |
| JE-314317 | 82.5 | 9.1:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -10.8 | 272 | NC |
| JE-314311 | 82.5 | 9.1:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -10.8 | 295 | NC |
| WK751M825 | 82.5 | 9.3:1 | 21 | 29.59 | Wiseco | Jupe | 2618 | NC | -10.8 | NC | 8250XX |
| WK750M825 | 82.5 | 9.5:1 | 21 | 29.59 | Wiseco | Jupe | 2618 | NC | -7.1 | NC | 8250XX |
| JE-329247 | 82.5 | 9.6:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -7.1 | 320 | NC |
| JE-353839 | 82.5 | 9.6:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -7.1 | NC | NC |
| JE-329244 | 82.5 | 9.6:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -7.1 | 320 | NC |
| JE-367860 | 82.5 | 9.6:1 | 21 | 29.3 | JE Ultra Series | Tête + Jupe | 2618 | FSR | -5.7 | 297 | NC |
| K9539DA | 82.5 | 9.6:1 | 21 | 29.6 | Wossner | NC | NC | NC | -7.3 | NC | GNH82.50 |
| K9487DA | 82.5 | 9.6:1 | 21 | 29.6 | Wossner | NC | NC | Round | -7.3 | NC | 825XPY |
| 43705-825 | 82.5 | 9.6:1 | NC | NC | ZRP | NC | NC | NC | NC | NC | NC |
| 43705-825 | 82.5 | 9.6:1 | NC | NC | ZRP | NC | NC | NC | NC | NC | NC |
| K9479DA | 82.5 | 9.8:1 | NC | NC | Wossner | NC | NC | NC | NC | NC | NC |
| K9479DA | 82.5 | 9.8:1 | NC | NC | Wossner | NC | NC | NC | NC | NC | NC |
| DIA-38110-4 | 82.5 | 10:1 | 21 | 29.59 | Diamond | Jupe | 2618 | NC | -4.5 | NC | 9513248 |
| DIA-38110-4-H | 82.5 | 10:1 | 21 | 29.59 | Diamond HD | Jupe | 2618 | NC | -4.5 | NC | 9513248 |
| JE-353842 | 82.5 | 10:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -4.5 | NC | NC |
| JE-314320 | 82.5 | 10.3:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -3 | 297 | NC |
| JE-314314 | 82.5 | 10.3:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -3 | 305 | NC |
| DIA-38107-4 | 83 | 8.6:1 | 21 | 29.59 | Diamond | Jupe | 2618 | NC | -15.5 | NC | 9513268 |
| DIA-38107-4-H | 83 | 8.6:1 | 21 | 29.59 | Diamond HD | Jupe | 2618 | NC | -15.5 | NC | 9513268 |
| DIA-38109-4 | 83 | 9.1:1 | 21 | 29.59 | Diamond | Jupe | 2618 | NC | -11.5 | NC | 9513268 |
| DIA-38109-4-H | 83 | 9.1:1 | 21 | 29.59 | Diamond HD | Jupe | 2618 | NC | -11.5 | NC | 9513268 |
| JE-314318 | 83 | 9.1:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -11.5 | 276 | NC |
| JE-314312 | 83 | 9.1:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -11.5 | 297 | NC |
| WK752M83 | 83 | 9.1:1 | 21 | 29.59 | Wiseco | Jupe | 2618 | NC | -11.5 | NC | 8300XX |
| WK750M83 | 83 | 9.5:1 | 21 | 29.59 | Wiseco | Jupe | 2618 | NC | -7.1 | NC | 8300XX |
| JE-329248 | 83 | 9.6:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -7.8 | 320 | NC |
| JE-353840 | 83 | 9.6:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -7.8 | NC | NC |
| JE-329245 | 83 | 9.6:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -7.8 | 320 | NC |
| JE-367861 | 83 | 9.6:1 | 21 | 29.3 | JE Ultra Series | Tête + Jupe | 2618 | FSR | -6.4 | 299 | NC |
| 43705-83 | 83 | 9.6:1 | NC | NC | NC | NC | NC | NC | NC | NC | NC |
| K9539D050 | 83 | 9.6:1 | 21 | 29.6 | Wossner | NC | NC | NC | -7.3 | NC | GNH83.00 |
| 43705-83 | 83 | 9.6:1 | NC | NC | ZRP | NC | NC | NC | NC | NC | NC |
| K9487D050 | 83 | 9.7:1 | 21 | 29.6 | Wossner | NC | NC | Round | -7.3 | NC | 830XPY |
| K9479D050 | 83 | 9.8:1 | NC | NC | Wossner | NC | NC | NC | NC | NC | NC |
| K9479D050 | 83 | 9.8:1 | NC | NC | Wossner | NC | NC | NC | NC | NC | NC |
| JE-353843 | 83 | 10:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -5.2 | NC | NC |
| DIA-38111-4 | 83 | 10.1:1 | 21 | 29.59 | Diamond | Jupe | 2618 | NC | -4.5 | NC | 9513268 |
| DIA-38111-4-H | 83 | 10.1:1 | 21 | 29.59 | Diamond HD | Jupe | 2618 | NC | -4.5 | NC | 9513268 |
| JE-314321 | 83 | 10.3:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -3.6 | 300 | NC |
| JE-314315 | 83 | 10.3:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -3.6 | 309 | NC |
| JE-314319 | 83.5 | 9.1:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -12.3 | 280 | NC |
| JE-314313 | 83.5 | 9.1:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -12.3 | 302 | NC |
| JE-329249 | 83.5 | 9.6:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -8.4 | 320 | NC |
| JE-353841 | 83.5 | 9.6:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -8.4 | NC | NC |
| JE-329246 | 83.5 | 9.6:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -8.4 | 320 | NC |
| JE-367862 | 83.5 | 9.6:1 | 21 | 29.3 | JE Ultra Series | Tête + Jupe | 2618 | FSR | -7 | 301 | NC |
| K9487D100 | 83.5 | 9.7:1 | NC | NC | Wossner | NC | NC | NC | NC | NC | NC |
| K9487D100 | 83.5 | 9.8:1 | 21 | 29.6 | Wossner | NC | NC | Round | -7.3 | NC | 835XPY |
| K9479D100 | 83.5 | 9.8:1 | NC | NC | Wossner | NC | NC | NC | NC | NC | NC |
| K9479D100 | 83.5 | 9.8:1 | NC | NC | ZRP | NC | NC | NC | NC | NC | NC |
| JE-353844 | 83.5 | 10:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -5.8 | NC | NC |
| JE-314322 | 83.5 | 10.3:1 | 21 | 29.6 | JE FSR | NC | 2618 | FSR | -4.3 | 303 | NC |
| JE-314316 | 83.5 | 10.3:1 | 21 | 29.6 | JE Round | NC | 2618 | Round | -4.3 | 313 | NC |
Compatibilités moteurs : CAEA, CAEB, CAWB, CBFA, CCTA, CCZA, CCZB, CDNB, CDNC, CFKA, CPMA, AXX, BHZ, BPY, BWA, BWJ, BYD, BZC, CDLA, CDLB, CDLC, CDLD, CDLF, CDLG, CDLH, CDLJ, CDMA, CRZA.
Véhicules d’origine équipés des moteurs 2.0 TFSI EA888 Gen 1 et EA113 :
| Marque | Modèle | Code moteur | Puissance | Années |
|---|---|---|---|---|
| Audi | A3 8P | CCTA | 200 ch | 2008 – 2012 |
| Audi | A4 B8 | CAEA | 180 ch | 2008 – 2011 |
| Audi | A4 B8 | CAEB | 211 ch | 2008 – 2015 |
| Audi | A5 8T | CAEA | 180 ch | 2008 – 2011 |
| Audi | A5 8T | CAEB | 211 ch | 2008 – 2015 |
| Audi | S3 8P | BHZ | 265 ch | 2006 – 2012 |
| Seat | Leon 1P FR | BYD | 200 ch | 2006 – 2012 |
| Skoda | Octavia II RS | AXX | 200 ch | 2005 – 2009 |
| Skoda | Octavia II RS | CCTA | 200 ch | 2009 – 2013 |
| Volkswagen | Golf V GTI | AXX | 200 ch | 2004 – 2005 |
| Volkswagen | Golf VI GTI | CCZA | 211 ch | 2009 – 2012 |
| Volkswagen | Golf VI GTI Ed35 | CDLG | 235 ch | 2011 – 2012 |
| Volkswagen | Scirocco III | CCTA | 200 ch | 2008 – 2014 |
