Prix réduit ! Radiateur huile BREEZY matrice 115mm 25 rangées DASH10 noir Agrandir l'image

Radiateur huile BREEZY matrice 115mm 25 rangées DASH10 noir

Attention : dernières pièces disponibles !

M115L25AN10

BREEZY

Neuf

Radiateur huile 25 rangées matrice 115mm raccordement DASH10

Plus de détails

75,06 € TTC

-40%

125,10 € TTC

18 Produits

DISPONIBLE EN STOCK

  • Radiateur huile BREEZY 25 rangées, matrice 115mm, connections: UNF-JIC 7/8"-14 (DASH10)





    Dimensions matrice 235mm :

    Epaisseur : 51mm

    Dimensions matrice 235mm (en mm)

    Nombre de rangées

    Hauteur hors connexions

    Connexions entrée/sortie

    Entraxe connexions

    Entraxe fixations

    Longueur totale

    7

    51

    Taraudage M12 x 150



    10

    77

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330

    13

    99

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330

    16

    123

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330

    19

    147

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330

    25

    193

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330

    34

    262

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330

    44

    347

    UNF-JIC 7/8’’-14 (DASH10)

    248

    308

    330





    Dimensions matrice 115mm :

    Epaisseur : 51mm

    Dimensions matrice 115mm (en mm)

    Nombre de rangées

    Hauteur hors connexions

    connexions entrée/sortie

    Entraxe connexions

    Entraxe fixations

    Longueur totale

    7

    51

    Taraudage M12 x 150

    128

    188

    210

    10

    77

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210

    13

    99

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210

    16

    123

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210

    19

    147

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210

    25

    193

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210

    34

    262

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210

    44

    347

    UNF-JIC 7/8’’-14 (DASH10)

    128

    188

    210
